Hardware Portfolio

Trackerwave Ovitag™ RTLS Hardware Portfolio

Enterprise-Grade IoT Infrastructure for Healthcare & Industry 4.0.

The Backbone of Real-Time Location Intelligence

Trackerwave offers a comprehensive range of hospital-grade and enterprise Real-Time Location Services (RTLS) hardware. Designed for precision, durability, and low cost of ownership, our hardware ecosystem supports multi-protocol technologies including Bluetooth Low Energy (BLE 5.0/5.1), Wi-Fi, RFID, and Ultra-Wide Band (UWB). All Trackerwave devices support secure Over-the-Air (OTA) firmware updates, mutual authentication, and are globally certified (CE, FCC, RoHS) for safe, seamless deployment.

Part 1

Multi-Spectrum IoT Gateways

Our gateways eliminate the need for extensive wiring, leveraging your existing network infrastructure to capture and transmit real-time location data securely.

Ovitag Wi-Fi IoT Gateway Reader

Ovitag Wi-Fi IoT Gateway Reader

A powerful multi-spectrum reader offering industry-best ranges, reducing the total number of installation points required across a facility.

  • Protocols: Wi-Fi (IEEE 802.11 b/g/n), BLE 5.0, UWB.
  • Built-in Sensors: Temperature, humidity, and pressure monitoring built directly into the gateway.
  • Security: Public/Private Key certificate infrastructure with mutual authentication and HTTPS/MQTT support.
Ovitag Power over Ethernet (PoE) Gateway

Ovitag Power over Ethernet (PoE) Gateway

A low-voltage, network-connected module that utilizes PoE technology for combined power and data control, ideal for robust enterprise deployments.

  • Power Input: 50 V (PoE) & 5V DC (Jack).
  • Range: Up to 25 meters (Bluetooth) and 30 meters (UWB).
Pluggable IoT Gateway

Pluggable IoT Gateway

A compact Bluetooth/Wi-Fi gateway in the shape of a standard power plug. Instantly scans nearby BLE devices and updates location information to the cloud.

Ovitag Mini IoT Gateway Reader

Ovitag Mini IoT Gateway Reader

A compact multi-spectrum reader offering localized precision, optimizing cost and density for smaller rooms or targeted facility zones.

  • Protocols: Wi-Fi (IEEE 802.11 b/g/n), BLE 5.0, UWB.
  • Security: Public/Private Key certificate infrastructure with mutual authentication and HTTPS/MQTT support.
Part 2

Wearable People Tags

Ergonomic, battery-efficient tags designed for the seamless tracking and safety of patients, staff, and visitors.

Smart Staff ID Card

Smart Staff ID Card

A unified badge combining Bluetooth 5.1 and RFID for indoor real-time tracking, access control, and automated attendance.

  • 3-axis accelerometer.
  • Programmable SOS duress button.
  • Up to 150 m range.
Staff & Patient E-Ink Coaster

Staff & Patient E-Ink Coaster

A two-way communication device featuring a crisp 3.7-inch e-ink display.

  • Designed for indoor/outdoor use (IP65 waterproof).
  • Displays patient names, queue tokens, or porter tasks.
  • Integrated vibration, LED, and buzzer alerts.
  • Rechargeable battery lasts up to 3 shifts.
Patient Wristband with SOS

Patient Wristband with SOS

A tiny, battery-powered BLE 5.0 tag designed for high-risk patient tracking and fall detection.

  • Built-in 3-axis accelerometer to detect falls.
  • Manual SOS button.
  • Safely sterilizable via Plasma, Ethyl Oxide (ETO), or Gamma.
Infant Safety Tag

Infant Safety Tag

An ultra-secure, skin-friendly neonatal tag that pairs with the mother's wearable to prevent abduction or mismatching.

  • Tamper-proof conductive band (circuit breaker alarm).
  • Continuous skin temperature monitoring.
  • IP67 waterproof rating.
Part 3

Asset & Environment Tracking

Durable, tamper-evident hardware built to track critical movable medical equipment and monitor sensitive environments.

Tamper-Proof Asset Tag

Tamper-Proof Asset Tag

Designed to secure and locate IV pumps, wheelchairs, and stretchers.

  • BLE 5.1 tracking with built-in accelerometer.
  • Rotatable housing for secure screw or adhesive mounting.
  • Tamper-evident alarms if forcibly removed.
  • Battery life spans up to 3–5 years.
Medical Record File Tag

Medical Record File Tag

A slim, lightweight BLE 5.1 tag specifically designed to be attached to physical medical records and batch folders to digitize their movement.

  • Accelerometer detects static vs. moving states.
  • Syncs real-time locations to the hospital's digital twin.
Environmental Sensor

Environmental Sensor

A robust, waterproof BLE sensor utilized for monitoring cold chain storage, blood banks, and freezers.

  • Highly accurate temperature and humidity monitoring.
  • Optional water leakage detection capabilities.
Part 4

Enterprise Safety & Sterilization Standards

Trackerwave hardware is engineered specifically for the rigorous demands of the healthcare environment.

Trackerwave certifications: CE, FCC, RoHS, ISO 9001, ISO 27001, SOC2, HIPAA

Infection Control Ready

Tags are manufactured from antimicrobial materials (ABS plastic/TPU) and are rated for stringent sterilization protocols including wiping, Gamma, Plasma, and Ethyl Oxide.

Industrial Durability

IP65 to IP67 waterproof ratings ensure devices survive liquid splashes, intensive cleaning, and outdoor conditions.

Regulatory Certifications

All hardware is certified under CE, FCC, and RoHS guidelines, with the broader platform complying with GDPR, HIPAA, and SOC2 data security frameworks.
